Martindale NC2 Non-contact Voltage Tester

  • Optimised for 230V single and 3 phase supplies
  • Audible and visual indication from 200V to 1000V AC
  • Extended probe for easy access
  • Clear tip for high visibility indication
  • LED torch for use in low light
  • Power on LED pulse and low battery indicator

CAT IV 1000V
EAN: 5036162188015 SKU: MARNC2 Category: Tags: ,

Description

The NC2 is a non-contact voltage tester for accurately detecting the presence of AC voltages between 200V and 1000V. When voltages are detected, a bright red LED illuminates the clear tip of the NC2 and a buzzer sounds.

It will indicate approximately 4mm from a conductor at 230V AC, making it ideal for tracing live circuits within cable containment and for voltage detection in sockets and junction boxes. The NC2 can be used to differentiate between Live and Neutral wires and detect blown fuses.

The pen-shaped design with clip makes it ideal for carrying in a pocket or tool belt when working at height or in difficult to access locations. A built-in torch in the tip is ideal for use in low light areas illuminating the area under test. Other NC2 features include low battery indication and LED pulse when on.

The NC2 replaces the Martindale VT2.

Specifications

Indication Range 200-100V AC
40-400Hz
Voltage Sensitivity indicates 4mm approx. from a conductor at 240V AC
Indication Audible and LED
Conforms to BS EN 61010-1
Supply 2x AAA batteries (included)
Weight 55g (incl. battery)
Dimensions 155mm length, approx. 25mm diameter

Comparison

NC1NC2NC3
AC Voltage Range200-1000V200-1000V
Frequency Range40-400Hz40-400Hz
Magnetic Field Detection> 10mT> 10mT
LED IndicationYellow LEDRed LEDYellow / Red LED
Audible Indication
Power On Pulse LED
Low Battery Indication
Auto Power Off
LED Torch

Datasheet

Download

Manual

Download

£22.00
