Martindale CP301 110V 32A Industrial Socket Tester

  • 110V centre tapped industrial socket tester for 32A supplies
  • Bright LED indication of wiring status
  • Identifies 7 fault conditions
  • Yellow 32A 3 pin plug to BS EN 60309 (BS 4343)

CAT II 150V
SKU: MARCP301/32 Category: Tag:

Description

The Martindale CP301 is an industrial socket tester for instantly checking sockets on 110V centre tapped circuits. It is fitted with a yellow 110V 32A CT plug to BS 4343/IEC309 and provides similar fail-safe LED indication as the classic check plug.

Using LEDs to highlight possible fault combinations, the CP301 is invaluable for instantly checking sockets on industrial or site installations. There is a look up chart on the tester for fast and simple fault diagnosis.

Specifications

Operating voltage 110V AC (55-0-55V centre tapped only)
Operating current 30mA
Overvoltage CAT II/150V
Temperature range -10 to 40°C at max, 60% RH
Complies with BS EN 61010-1
Dimensions 65 x 65 x 47mm (check plug body)
Weight 195g approx.
Includes manual

Datasheet

Download

Manual

Download

£58.00
