Martindale AV90 Vane Anemometer with External Probe

  • Measure Airflow & Temperature
  • Up to 8 Min / Max readings stored
  • Temperature up to +60°C
  • Measures metres/second, feet/minute, knots, mph or kph

EAN: 5036162184802 SKU: MARAV90 Category:

Description

The Martindale AV90 thermo anemometer displays temperature in °C or °F, and airflow, at the same time. It has a large, external vane probe for taking measurements in awkward areas.

Minimum and maximum values for flow and temperature can be shown. More accurate measurements can also be made, by taking 8 readings which are then automatically averaged. In addition, measurements can also be taken over 2 or 16 seconds, with the average of 2 or 16 readings being displayed.

The anemometer will display airflow readings in metres/second, feet/minute, knots, mph or kph.

Unit is supplied with battery, instruction manual and external vane probe.

Specifications

Temperature measurement range -20°C to 60°C / -4°F to 140°F
Resolution 0.1°C /°F
Accuracy ±0.5°C at +0°C to +45°C, ±1.0°C at -20°C to 0°C and 45°C to 60°C

±1°F at 32°F to 113°F, ±2.0°F at +4°F to 32°F and 113°F to 140°F

Wind velocity measurement range 0.3-30 m/s, ±0.01

60-5900 ft/min, ±1

0.6-58 knots, ±0.1

0.7-67 mph, ±0.1

1.1-108 km/h, ±0.1

Accuracy ±3 FS
Supply 9V battery (PP3, NEDA 1604, IEC 6F22 006P)
Weight 390d approx.
Dimensions 770 x 65.5 x 35mm
Includes battery and manual

Datasheet

Download

Manual

Download

£189.00
